MS852+ ESD

ESD-safe 2D Imager Scanner

The MS852+ ESD (Electrostatic discharger) 2D imager scanner is a high-performance device but additional designed to satisfy the stringent requirements of cleanrooms and static-safe manufacturing environments.

Unitech’s MS852+ ESD-safe scanner features an internal antistatic agent to provide a completely ESD-safe solution that even protects its cable. The scanner body and its cable can withstand ESD up to 105 ~109 ohms per square and contain no chlorine.



Features

•  Withstands ESD up to 105~109 ohms per square
•  Megapixel barcode sensor that provides maximum compatibility
•  Supports most 1D / 2D barcode on mobile screens, even damaged or poorly printed barcodes
•  Supports OCR, Dot codes, and Digimarc barcodes
•  Excellent motion tolerance design suitable for reading bar code while moving
•  Long lifecycle trigger design: Up to 10,000,000 times.
•  Ultra-rugged design: IP42 and 2.1m drop spec
•  Louder beep and brighter LED indicators for easily recognized feedback

MS85X ESD Series | Successful Cases


Our MS85X ESD Series has become a trustworthy partner for nationwide renowned electronic enterprises, such as Micron, ASE Group, SPIL, etc. In anti-static cleanrooms, a manufacturing environment following ESD-safe regulations can significantly reduce damage to electronic components and failure to onsite equipment. Check out how they lead to success with the latest Case Study.





Safeguard with unitech ESD-Safe Scanners


Specifically designed to satisfy the stringent requirements of static-safe environments

Introducing the new MS85x ESD (Electrostatic Discharger) series of high-performance 1D Laser and 2D Imager, USB corded, and cordless (Bluetooth®). unitech barcode scanners are specifically designed to satisfy the stringent requirements of static-safe environments such as manufacturing (semi-conductor), gas station, fuel grounds, mining fields, clean-rooms, and other situations that require electrostatic discharge control.
Applications

Manufacturing  |    Gas Station
Fuel grounds |  Mining fields  | Clean-rooms





ESD Protection


The MS852+ ESD (Electrostatic discharger) imager is a high-performance device but additional designed to satisfy the stringent requirements of cleanrooms and static-safe manufacturing environments. unitech’s MS852+ ESD-safe scanner is made by internal mixed way with antistatic agent to protect MS852+ series to be ESD safe to be used at ESD protected area including its cable. With the Internal mixed way, the body of the product and its cable can withstand ESD up to 105~109 ohms per square and no containing Chlorine material. The Internal mixed way can provide a longer time of ESD protection than external addition way due to external additional anti-static in the latter part of the packaging or processing process was wiped away. An internal mixed antistatic agent can continue to add antistatic agent to the plastic surface, to make up the surface due to wipe and the amount of antistatic agent consumed. It is a reliable tool to streamline your workflow in manufacturing environments.



Increase Productivity with Superior Industrial Barcode Scanner



Specially built for challenging work environment, the MS852+ ESD is built in Megapixel barcode sensor that enhances the maximum compatibility to capture most 1D / 2D barcodes on mobile screens, even damaged or poorly printed barcodes and special barcode symbologies such as OCR on passport, Dot codes on tires or cigarette package, and Digimarc barcode on special retail packages. MS852+ ESD also can automatically populate electronic forms in a single scan from US driver’s licenses or ID card.  With its advanced barcode technology and durable design, the MS852+ ESD handheld scanner is a highly reliable tool to increase productivity and efficiency.

Intuitive and User-Friendly



With excellent motion tolerance design, the MS852+ ESD increased scan speed and operational effectiveness even while moving. Equipped with a louder beeper and brighter LED indicators, the MS852+ ESD allows users to recognize the feedbacks easily even in dark environment.

Ultra-Durability



While sustaining a 2.1 meter drop to concrete, MS852+ ESD incorporated with IP42 rugged design for protection against dust and moisture.  Moreover, the built-in long lifecycle trigger of 10 million times guarantees a continuous productivity for best reliability. This scanner can be used in the most practical way depending on the scanning task in various solutions in retail, logistics, manufacturing, hospitality, and government.

Specification

Model Numbers

  • SKUs MS852-ZUCB00-LG: MS852+ ESD, 2D Imager HD, N6703, OPOS, JPOS, USB Cable
